Description
SPECIFICATIONS:
Hardware |
|
Interfaces |
1*10/100/1000Mbps RJ45 |
Antenna Type |
2 * 5dBi dual-band antennas |
Button |
1 * WPS Button 1 * Reset Button |
LED Indicator |
1 * Signal LED |
Power Supply |
12V1A, built-in |
Power Consumption |
11W (max power consumption) |
Dimension |
123*72*47.5mm(L x W x H) |
Wireless |
|
Wireless Standard |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax |
Frequency |
5 GHz(11ax) 2.4 GHz |
Data Rate |
5GHz: Up to 1201Mbps 2.4GHz: Up to 574Mbps |
RSSI |
2.4 GHz 11b-1M:-97dBm 11g-54M:-76dBm 11n-20M-MCS7:-74dBm 11n-40M-MCS7:-72dBm 5 GHz: 11a-6M:-95dBm 11n-20M-MCS7:-74dBm 11n-40M-MCS7:-72dBm 11ac-80M-MCS9:-63dBm |
Transmission Power |
<20dBm |
Wireless Modes |
Repeater Mode，Access Point Mode |
Wireless Security |
|
Default encryption mode: |
Mix WPA-PSK/WPA2-PSK/WPA3 |
WPA algorithm: |
TKIP |
Others |
|
Certification |
CE, FCC RoHS |
Environment |
|
Operating Temperature: |
0℃~40℃ |
Storage Temperature: |
-40℃~70℃ |
Operating Humidity |
: (10~90)% RH, non-condensing |
Storage Humidity: |
(5~90)%RH, non-condensing |
