Description
SPECIFICATIONS:
HARDWARE |
|
RAM |
128MB |
Flash |
8MB |
Interfaces |
4*GE(1~3 WAN/ 1~3 LAN) |
Maximum Power Consumption |
12W |
Button |
1* Reset button |
Power |
12V 1A |
Dimension |
220*135*30mm |
WIRELESS |
|
Frequency |
2.4GHz\5GHz |
Wireless Speed |
300+867Mbps |
SOFTWARE |
|
Maximum user capacity |
80 |
Maximum user capacity |
50 |
Internet Connection Type |
PPPoE/DHCP/Static IP/Russian L2TP/India (PPPoE supports server name customization) |
Authorization Service |
Captive Portal/Facebook Authentication |
Captive Portal |
50 Portal Accounts Customize E-bulletin |
Bandwidth |
Smart Bandwidth Control Manual Definition |
Internet Access Control |
IP/mac/URL Filter |
VPN Protocol |
PPTP/L2TP/IPSEC |
Port Forwarding |
Port Forwarding DMZ |
Security Setting |
IP-MAC Binding ARP Attack Protection |
DDNS |
no-ip/dyndns |
UPNP |
Support |
Firmware Upgrade |
Local/online Upgrade |
System Tool |
Schedule Reboot Restore or Backup Configuration |
Network Status View |
Traffic Statistics Network structure topology |
OTHERS |
|
Package Contents |
Wireless Router*1 Power Adapter*1 Install Guide*1 |
Web Login Address |
tendawifi.com or 192.168.0.252 |
Operation Temperature |
0℃ ~ 40℃ |
Storage Temperature |
-40℃ ~ 70℃ |
Operating Humidity |
10% ~ 90% RH non-condensing |
Storage Humidity |
5%~90% RH non-condensing |
Certification |
CE/FCC/RoHS |
