Description
SPECIFICATIONS:
HARDWARE |
|
Dimension |
86*86*32mm |
Interfaces |
1*10/100/1000 Mbps PoE+Data Input LAN 1*10/100/1000 Mbps Ouput LAN |
Button |
1*Reset |
Antenna |
4dBi+5dBi |
Maximum Power Consumption |
8.5W |
LED Indicator |
1*SYS |
Power Supply |
PoE 802.3af |
WIRELESS |
|
Frequency Range |
2.4GHz & 5GHz dual band |
Maximum wireless speed |
2.4GHz:574Mbps 5GHz:2402Mbps |
Standard&Protocol |
IEEE 802.11b/g/n/ac/ax(wave2) |
Reception Sensitivity |
2.4GHz 802.11b -95.5dBm 2.4GHz 802.11n (MCS7) -72.5dBm 5GHz 802.11a -97.5dBm 5GHz 802.11n (MCS7) -77.5dBm |
SOFTWARE |
|
MU-MIMO |
Support |
Operating Mode |
AP/Client+AP |
Max. No. of SSID |
2.4GHz: 8 5GHz: 8 |
Hide SSID |
Support |
WEP |
Support |
WPA-PSK |
Support |
WPA2-PSK |
Support |
WPA |
Support |
WPA2 |
Support |
Access control |
Support |
Adjustable power transmit |
Support |
AP isolation |
Support |
Connected clients control |
Support |
RSSI Threshold |
Support |
WMM |
Support |
VLAN tagging for SSID |
Support |
LED control |
Support |
Diagnostics |
Support |
Schedule Reboot |
Support |
Reboot at specified interval |
Support |
System Logs |
Support |
Firmware upgrade |
Support |
Reboot |
Support |
Reset Button |
Support |
Backup configuration |
Support |
Restore configuration |
Support |
Centralized Management |
M3 or Tenda Router with AP Controller feature |
OTHERS |
|
Operation Temperature |
-10℃ ~ 40℃ |
Storage Temperature |
-30℃ ~ 70℃ |
Operating Humidity |
10%~90% non-condensing |
Storage Humidity |
5%~90% non-condensing |
Default login IP |
192.168.0.254 |
Certification |
CE/RoHS |
