Description
SPECIFICATIONS:
HARDWARE FEATURES |
|
Standard & Protocol |
IEEE802.3, IEEE802.3u,IEEE802.3ab，IEEE802.3bz |
CPU |
Dual-Core 1GHz CPU |
RAM |
512MB |
Interface |
1*10/100/1000/2500Mbps WAN/LAN port 3*10/100/1000Mbps WAN/LAN ports |
Antenna |
5*external antennas |
Button |
1*Mesh/Reset button |
Power |
Input: AC 100-240V~50/60Hz Output: DC 12V⎓1.5A |
LED indicator |
1* LED |
Dimensions |
(L*W*H) 244*56*200mm |
WIRELESS FEATURES |
|
Wireless Standards |
IEEE 802.11be/ax/ac/n/a 5 GHz IEEE 802.11be/ax/n/b/g 2.4 GHz |
Data Rate |
2.4G: 2412-2472MHz(CH1-CH13) 5G: 5150-5350MHz(CH36-CH64) 5725-5850MHz(CH149-CH165) |
Frequency |
5 GHz: 4323 Mbps (802.11BE, HE160) 2.4 GHz: 688 Mbps (802.11BE) |
Transmission Power |
SSID broadcasting and hiding MU-MIMO Beamforming signal directional transmission technology OFDMA |
Wireless Security |
WPA2-PSK WPA3-SAE/WPA2-PSK Wireless Security: Enable/Disable WPS(WiFi Protected Set-up) fast encryption |
SOFTWARE FUNCTION |
|
Internet Connection Type |
PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
Network Protocol |
IPv4&IPv6 |
Operating Mode |
Router Mode AP Mode Universal Repeater Mode（Client+AP,WISP） |
DHCP |
DHCP Server DHCP Client List DHCP Static IP Address Reservation and Allocation |
Parental Control |
Client Filter URL Filter Time Limit |
Virtual Server |
Port Forwarding DMZ Host UPnP |
Firewall |
ICMP Flood Attack Defense TCP Flood Attack Defense UDP Flood Attack Defense Block Ping From WAN |
DDNS |
DynDNS, no-ip, oray, 88ip |
VPN |
IPSec Transparent Transmission PPTP Transparent Transmission L2TP Transparent Transmission PPTP VPN Server PPTP VPN Client L2TP VPN Client |
Special Features |
WAN/LAN Port Auto-Negotiation Wi-Fi+(Mesh System) Smart Diagnosis IPTV IPv6 Smart LED on/off |
Other Function |
Support App and web management Bandwidth Control Guest Network MAC Address Clone Supports black list and white list Unify 2.4 GHz & 5 GHz Static Routing Remote Web Management Backup & Restore configurations Firmware upgrade online |
OTHER FEATURES |
|
Certification |
CE, FCC,RoHS |
Temperature |
Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ |
Humidity |
Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
Package Content |
Wi-Fi Router *1 CAT-6 Network Cable*1 NFC Sticker*1 Power Adapter*1 Quick Installation Guide*1 |
