SPECIFICATIONS:
|
BASIC INFORMATION
|
|
|
Installation
|
Desktop, rack installation
|
|
Dimensions (L*W*H)
|
294 *178.8 *44 mm
|
|
Application Scenario
|
Office,Home,School,Retail,CCTV,etc.
|
|
Operation Mode
|
Router Mode, AC Mode
|
|
PERFORMANCE PARAMETERS
|
|
|
Max. Client Capacity
|
150
|
|
Recommended Client Capacity
|
100
|
|
Recommended Broadband
|
1000Mbps
|
|
Max. New Sessions
|
4000
|
|
Max. Concurrent Sessions
|
49000
|
|
NAT (Static IP)
|
940Mbps/930Mbps
|
|
NAT(DHCP)
|
941Mbps/932Mbps
|
|
NAT(PPPoE)
|
914Mbps/924Mbps
|
|
AP Management
|
Router mode: 128
AC mode: 256
|
|
VLAN
|
4
|
|
HARDWARE PARAMETERS
|
|
|
CPU
|
Dual Core，1.0GHz
|
|
RAM
|
128 MB
|
|
FLASH
|
16 MB
|
|
Ports
|
5*GE (Max. 4 WAN, Max. 4 LAN)
|
|
Button
|
Reset Button
|
|
USB
|
1*USB
|
|
Standards and Protocols
|
IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, DDNS
|
|
Power Supply
|
Build-in power
|
|
SOFTWARE PARAMETERS(ROUTER)
|
|
|
AP Management
|
128APs
|
|
DHCP Server
|
DHCP Server(User/AP),DHCP Reservation
|
|
Wireless Policy
|
AP Group,SSID Policy,RF Policy,Vlan Policy,maintenance policy,Alarm Policy,Deployment Policy
|
|
Fast Roaming
|
802.11k,v,r
|
|
IPTV
|
IPTV Policy
|
|
ACL
|
IP/MAC/URL/PORT
|
|
Bandwidth Control
|
Based on single user, user group, smart bandwidth control
|
|
VPN
|
IPSec, PPTP, L2TP
|
|
Virtual Server
|
DMZ, DDNS, DNS Hijacking,IP Hijacking,UPNP,Port Mirroring,Port Mapping,DNS Cache
|
|
IPV6
|
Support
|
|
WAN Load Balancing
|
Intelligent Load Balancing,Customize
|
|
Routing
|
Static Routing,Policy Routing
|
|
Security
|
IP-MAC binding, Block Ping from WAN,DDoS Attack Defense,ARP Attack Defense,Binary Association
|
|
System Tools
|
ntp,Scheduled reboot, Diagnosis
|
|
System Log
|
system log,Operating log,Running log
|
|
System Account
|
Administrator,Visitor,Login IP Address Limit
|
|
Upgrade
|
Local,Online
|
|
Maintenance
|
Restore,Backup,Remote WEB Management
|
|
Management
|
http/https
|
|
SOFTWARE PARAMETERS(AC)
|
|
|
AP Management
|
256APs
|
|
DHCP Server
|
DHCP Server(User/AP),DHCP Reservation
|
|
Wireless Policy
|
AP Group,SSID Policy,RF Policy,Vlan Policy,maintenance policy,Alarm Policy,Deployment Policy
|
|
Fast Roaming
|
802.11k,v,r
|
|
IPTV
|
IPTV Policy
|
|
Security
|
Block Ping from WAN,DDoS Attack Defense,ARP Attack Defense,Binary Association
|
|
System Tools
|
ntp,Scheduled reboot, Diagnosis
|
|
System Log
|
system log,Operating log,Running log
|
|
System Account
|
Administrator,Visitor
|
|
Upgrade
|
Local,Online
|
|
Maintenance
|
Restore,Backup,Remote WEB Management
|
|
Management
|
http/https
|
|
OTHER PARAMETERS
|
|
|
Environment
|
Operating Temperature: -10℃-45°C
Operating Humidity:10%-90% RH, non-condensing
Storage Temperature: -40°C-70°C
Storage Humidity: 5%-90% RH, non-condensing
|
|
