Description
SPECIFICATIONS:
HARDWARE |
|
Dimension |
Φ178*38 mm |
Ethernet Interface |
One 10/100/1000 Mbps Ethernet Port (PoE) |
Antenna |
2*4 dBi |
Button |
1*Reset |
LED Indicator |
RGB |
Maximum Power Consumption |
14.04W |
Power supply standard |
IEEE 802.3at PoE |
WIRELESS |
|
Frequency Band |
2.4 GHz, 5 GHz |
Data Rate |
2.4 GHz data rate:1-574 Mbps 5 GHz data rate:6-2402 Mbps |
Wireless Standard |
IEEE 802.11a/b/g/n/ac/ax |
Channel width |
20 MHz/40 MHz/80 MHz/160 MHz |
Sensitivity |
2.4 GHz Max. output power:27+/-1.5 dBm 5 GHz Max. output power:26+/-1.5 dBm |
Max Transmit Power |
802.11b RX sensitivity:-99 dBm 2.4 GHz 802.11n (MCS7) RX sensitivity:-78dBm 5 GHz 802.11a RX sensitivity:-97 dBm 5 GHz 802.11n (MCS7) RX sensitivity:-77 dBm |
SOFTWARE |
|
MU-MIMO |
2X2 MU-MIMO |
Operating Mode |
AP.Client+AP |
Hide SSID |
Supported |
Max. No. of SSID |
2.4GHz: 8 5GHz: 8 |
Max. connected clients |
254 |
WEP |
Supported |
802.11 k/v |
Supported |
Fast roaming |
Supported |
TWT |
Supported |
Beamforming |
Supported |
OFDMA |
Supported |
WPA-PSK |
Supported |
WPA2-PSK |
Supported |
WPA3-ASE |
Supported |
WPA |
Supported |
WPA2 |
Supported |
Access control |
Supported |
Adjustable power transmit |
Supported |
AP isolation |
Supported |
Frequency analysis |
Supported |
Connected clients control |
Supported |
RSSI Threshold |
Supported |
WMM |
- |
VLAN tagging for SSID |
Supported |
LED control |
Supported |
Diagnostics |
Ping, Traceroute |
Schedule Reboot |
Supported |
Reboot at specified interval |
Supported |
Centralized Management |
- |
System Logs |
Supported |
Firmware upgrade |
Supported |
Reboot |
Supported |
Reset Button |
Supported |
Backup configuration |
Supported |
Restore configuration |
Supported |
OTHERS |
|
Default login IP |
192.168.0.254 |
Default Login Username |
admin |
Default Login Password |
admin |
Operation Temperature |
-10℃ - 45℃ |
Operating humidity |
(10% - 90%) RH, non-condensing |
Storage temperature |
-30℃ - 70℃ |
Storage humidity |
(10% - 90%) RH, non-condensing |
