HARDWARE
|
|
|
Standard&Protocol
|
IEEE802.11a/b/g/n/ac
IEEE 802.3, IEEE 802.3u, IEEE 802.4ab
|
|
Ethernet Interface
|
2 x 10/100/1000Mbps RJ45 ports per node
|
|
Antenna
|
2 x Internal antenna
|
|
Button
|
1 x Reset Button
|
|
Power
|
Input: 100-240V—50/60Hz, 0.6A
Output: 12V1A
|
|
Dimension
|
100 x 100 x 100mm (3.94 x 3.94 x 3.94in)
|
|
LED Indicator
|
1 x Tri-color LED
Indicator(Green,Yellow,Red)
|
|
WIRELESS
|
|
|
Wireless Standard
|
IEEE802.11a/b/g/n/ac (WiFi 5 wave 2)
|
|
Wireless roaming
|
Comply with IEEE802.11k/v/r
|
|
Mesh network Standard
|
IEEE802.11s
|
|
Rate
|
2.4GHz: 300Mbps
5GHz: 867Mbps
|
|
Frequency
|
2.4~2.4835GHz
5.15~5.25GHz
5.725~5.85GHz
|
|
Transmission Power
|
CE:
<20dBm(2.4G)
<23dBm(5G)
Basic Features
SSID Broadcast
Beam Forming
MU-MIMO
AP Steering
Band Steering
|
|
Wireless Security
|
WPA-PSK/WPA2-PSK(default)
|
|
SOFTWARE
|
|
|
Operating Mode
|
Router Mode,Bridge Mode
|
|
Internet Connection Type
|
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
|
|
DHCP Server
|
DHCP Server, DHCP Client List
|
|
Virtual Server
|
Port Forwarding, UPnP
|
|
Parental Control
|
Client Filter
|
|
Firewall
|
Forbid TCP/UDP flood attack
|
|
VPN
|
PPTP/L2TP/IPsec pass through
|
|
DNS
|
Support manually setting DNS server
|
|
Special Features
|
Smart QoS (Gaming, Video & Audio, Download)
|
|
Others
|
Auto-sensing internet connection
Support App management and Remote management
Guest Network
Firmware upgrade online
|
|
OTHERS
|
|
|
Operation Temperature
|
0 ~ 40 ℃
|
|
Storage Temperature
|
-40 ~ 70 ℃
|
|
Operating Humidity
|
10%~90% RH non-condensing
|
|
Storage Humidity
|
5%~90% RH non-condensing
|
|
APP installation
|
Available in iOS 8.0 or later, Android 4.0 or later
|
|
Certification
|
CE, FCC, RoHS,EAC,IC
|
|
Package Contents
|
Mesh3 x 2, Power adapter x 2, QIG x 1, RJ45 Gigabit Ethernet cable x 1
|
