HARDWARE
|
|
|
Standard&Protocol
|
IEEE802.3, IEEE802.3u,IEEE802.3ab
|
|
Interfaces
|
1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports
|
|
Antenna
|
5*6dBi external antennas
|
|
Button
|
1* WP1*Reset button
|
|
Power
|
Input：AC 100-240V~50/60Hz 0.6A
Output：DC 12V⎓1.5A
|
|
Dimension
|
267*166*222 mm
|
|
LED Indicator
|
SYS*1
|
|
WIRELESS
|
|
|
Wireless Standard
|
IEEE 802.11ac/a/n/ax 5GHz
IEEE 802.11b/g/n/ax 2.4GHz
|
|
Data Rate
|
5GHz: Up to 2402Mbps
2.4GHz: Up to 574Mbps
|
|
Frequency
|
Simultaneous dual band 2.4 & 5GHz
|
|
Transmission Power
|
CE:
<20dBm(2.4G)
<23dBm(5G)
|
|
Basic Features
|
SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
MU-MIMO
|
|
Wireless Security
|
WPA-PSK,WPA2-PSK, WPA/WPA2-PSK
WPA3-SAE/WPA2-PSK
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up) fast encryption
|
|
SOFTWARE
|
|
|
Internet Connection Type
|
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Unify,Maxis,Maxis-special,Celcom,Digi
|
|
Operating Mode
|
Wireless Router Mode
Universal Repeater Mode（Client+AP,WISP）
|
|
DHCP Server
|
DHCP Server
DHCP Client List
DHCP Reservation
|
|
Virtual Server
|
Port Forwarding
DMZ Host
UPnP
|
|
Security
|
Client Filter
Parental Control(support black list and white list)
Remote Web Management
|
|
Firewall
|
Forbid UDP flood attack
Forbid TCP flood attack
Forbid ICMP attack
Forbid WAN PING from internet
|
|
DDNS
|
DynDns, NO-IP, Oray.com, 3322.org, 88ip
|
|
VPN
|
PPTP Client
PPTP Server
L2TP Client
PPTP Pass Through
L2TP Pass Through
IPSec Pass Through
|
|
Special Features
|
WiFi+(Mesh System)
Smart diagnosis
VLAN
TR069
Smart Traffic Prioritisation
Smart WiFi Schedule
Smart LED on/off
|
|
Others
|
IPTV
PPPoE Username/password Clone
Tenda App
Bandwidth Control
Guest Network Remote Web Management
MAC Clone
Backup & Restore configurations
Support automatic access detection
Firmware upgrade online
Firmware upgradeable via browser
|
|
OTHERS
|
|
|
Temperature
|
Operating Temperature : 0℃~40℃
Storage Temperature : -40C ~70℃
|
|
Humidity
|
Operating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing
|
|
Default Settings
|
Default Access: tendawifi.com
|
|
Certification
|
CE, RoHS, FCC
|
|
EIRP Power (Max)
|
2.400-2.4835 GHz:19.83dBm(EIRP)
5.150-5.250 GHz:22.98dBm(EIRP)
|
|
Package Contents
|
Wireless Router*1
Power Adapter *1
Install Guide*1
Ethernet Cable*1
|
