Description
SPECIFICATIONS:
STORAGE |
|
Disk Slot Number |
6 |
Compatible Disk Types |
3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
File System |
NTFS, APFS, Mac OS,FAT32,EXT4,exFAT |
Maximum Internal Raw Capacity |
132 TB (22 TB drive x 6) (Capacity will vary along with the RAID type) |
RAIDs Supported |
SINGLE DISK |
Hardware RAID |
/ |
RAID Manager Software |
/ |
RAID Manager Software Language |
/ |
RAID Online Expansion |
/ |
RAID Migration |
/ |
RAID Auto-rebuilding |
/ |
Drive Hot Swap |
√ |
HDD Sleep |
√ |
HDD S.M.A.R.T. Inspection |
/ |
Sector Inspection and Parity Check |
/ |
SSC Cache |
/ |
Daisy Chain |
/ |
HDD NCQ Technology |
/ |
Alert Notice |
/ |
Event Log |
/ |
EXTERNAL PORTS |
|
USB |
USB3.2 Type-C gen2 10Gbps |
Thunderbolt |
/ |
DP Interface |
/ |
Network Interface |
/ |
USB HOST Interface |
/ |
Power Socket |
DC IN 12V |
READING/WRITING SPEED (MAX.) |
|
Reading Speed (max.) |
Read：520MB/s ( SSD* 1 ); Read：1016MB/s ( SSD* 6 )； |
Writing Speed (max.) |
Write：500MB/s ( SSD*1 ); Write：986MB/s ( SSD*6 )； |
APPEARANCE |
|
Size (H*W*D) |
226 x 130 x 218 mm |
Packaging Size (H*W*D) |
312 x 189 x 267 mm |
Weight |
Net weight: 3.4 Kg |
OTHERS |
|
System fan |
80 mm x 80 mm x25mm (x 2) |
Fan mode |
Smart |
Noise Level |
28.4dB(A) |
POWER SUPPLY |
|
Power Supply |
120 W |
AC Input Voltage |
100V to 240V AC |
Current Frequency |
50/60 HZ, Single Phase |
Power Consumption |
2.0 W(Access) |
ENVIRONMENT TEMPERATURE |
|
Working Temperature |
0°C ~ 40°C (32°F ~ 104°F) |
Storage Temperature |
-20°C ~ 60°C (-5°F ~ 140°F) |
Relative Humidity |
5% ~ 95% RH |
OTHERS |
|
Supported OS |
Windows OS、Mac OS、Linux |
Certificate |
CE, FCC, CCC, KC |
Environment |
RoHS compliance |
Package Contents |
Host unit (x1) Power cord (x1) USB Cable C to Type-C (10Gb) (0.8mx1)；USB Cable A to Type-C (10Gb) (0.8mx1) Quick Installation Guide (x1) Power adapter (x1) Screws (several) Limited Warranty Note x 1 |
