Description
DISCLAIMER: The RAID software is not compatible with MAC version 14.x - Sonoma - with no ETA for development.
SPECIFICATIONS:
STORAGE |
|
Disk Slot Number |
5 |
Compatible Disk Types |
3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
File System |
NTFS, APFS, Mac OS,FAT32,EXT4,exFAT |
Maximum Internal Raw Capacity |
100TB (20 TB drive x 5) (Capacity will vary along with the RAID type) |
RAIDs Supported |
Support RAID 0、RAID 1、RAID 5、RAID 10、CLONE、JBOD、Single Disk |
Hardware RAID |
√ |
RAID Manager Software |
√ |
RAID Manager Software Language |
English, Chinese, Japanese, German, French, Spanish, Italian |
RAID Online Expansion |
/ |
RAID Migration |
/ |
RAID Auto-rebuilding |
/ |
Drive Hot Swap |
/ |
HDD Sleep |
√ |
HDD S.M.A.R.T. Inspection |
/ |
Sector Inspection and Parity Check |
/ |
SSC Cache |
/ |
Daisy Chain |
/ |
HDD NCQ Technology |
/ |
Alert Notice |
/ |
Event Log |
/ |
EXTERNAL PORTS |
|
USB |
USB3.1 Type-C gen1 x 1 |
Thunderbolt |
/ |
DP Interface |
/ |
Power Socket |
DC IN 12V |
READING/WRITING SPEED (MAX.) |
|
Reading Speed (max.) |
Read：210MB/s (2 SSHD RAID0 mode) |
Writing Speed (max.) |
Write：190MB/s (2 SSHD RAID0 mode) |
APPEARANCE |
|
Size (H*W*D) |
227 x 225 x 136 mm |
Packaging Size (H*W*D) |
300 x 275 x 186 mm |
Weight |
Net Weight: 2.1Kg Gross Weight: 3.5Kg |
OTHERS |
|
System fan |
80 mm x 80 mm x25mm (x 2) |
Fan mode |
Smart |
Noise Level |
19.8dB(A) |
POWER SUPPLY |
|
Power Supply |
90W |
AC Input Voltage |
100V to 240V AC |
Current Frequency |
50/60 HZ, Single Phase |
Power Consumption |
45.6W(Access) |
ENVIRONMENT TEMPERATURE |
|
Working Temperature |
5°C ~ 40°C (40°F ~ 104°F) |
Storage Temperature |
-20°C ~ 60°C (-5°F ~ 140°F) |
Relative Humidity |
5% ~ 95% RH |
Supported OS |
Windows OS、Mac OS |
Certificate |
CE, FCC, CCC, KC |
Environment |
RoHS compliance |
Package Contents |
Host unit (x1) Power cord (x1) USB Cable A to Type-C(10Gb) (x1) Quick Installation Guide (x1) Power adapter (x1) Screws (several) |
