Manufacturer Warranty: 3 Year
|
 SPECIFICATIONS:
|
Case type
|
Full Tower
|
|
Dimension (H X W X D)
|
565.2 x 327 x 599.2 mm
(22.25 x 12.87 x 23.59 inch)
|
|
Net weight
|
4.50 kg / lbs.
|
|
Side panel
|
4mm Tempered Glass x 2
|
|
Color
|
White
|
|
Material
|
SPCC / ABS
|
|
Cooling system
|
Front(intake):
140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
Top(exhaust):
140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
Rear(intake):
140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1
|
|
Expansion slots
|
7
|
|
Motherboards
|
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX)
|
|
I/O port
|
USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 4, HD Audio x 1
|
|
PSU
|
Standard PS2 PSU (optional)
|
|
Fan support
|
Front:
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
2 x 200mm, 1 x 200mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Right (M/B Side):
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
Rear:
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
2 x 200mm, 1 x 200mm
Bottom:
3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
|
|
Radiator support
|
Front:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm
Top:
1 x 240mm, 1 x 120mm
1 x 140mm
Right (M/B Side):
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm
Rear:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm
Bottom:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
|
|
Clearance
|
CPU cooler max height:
190mm
VGA max length:
370mm (With radiator)
420mm (Without radiator)
PSU max length:
220mm
|
|
|
