Description
SPECIFICATIONS:
Series |
CTE |
Case Type |
Mid Tower |
Dimension (H x W x D) |
558.5 x 270 x 513mm (21.99 x 10.63 x 20.2 inch) |
Net Weight |
14.5 kg / 31.97 lbs. |
Panel |
4mm Tempered Glass x 3 |
Color |
Gravel Sand |
Material |
SPCC |
Cooling System |
3 x 3.5”, 1 x 2.5” or 2 x 3.5”, 2 x 2.5” |
Expansion Slots |
7 |
Motherboards |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 10.5” (E-ATX) |
I/O Port |
USB 3.0 x 2, Type-c x1, HD Audio x 1 |
PSU |
Standard PS2 PSU (optional) |
Fan Support |
Top: 2 x 120mm, 1 x 120mm
Right (M/B Side): 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm ,2x 140mm, 1 x 140mm
Bottom: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm ,2x 140mm, 1 x 140mm |
Radiator Support |
Top: 1 x 240mm, 1 x 120mm
Right (M/B Side): 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm, 1 x 280mm, 1 x 140mm
Bottom (DIY only): 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm, 1 x 280mm, 1 x 140mm |
Clearance |
CPU cooler max height: 166mm VGA max length: 415mm (with radiator) 443.8mm (without radiator) PSU max length: 220mm |
