Description

SPECIFICATIONS:
Compatibility |
Intel: LGA 2066/2011/2011-3/1851/1700/1200/1156/1155/1151/1150 AMD : AM5 /AM4 |
Dimensions |
Standard: 148.6 x 146.6 x 165 mm ( L x W x H) 48mm RAM Compatibility: 148.6 x 146.6 x 188.5 mm ( L x W x H) |
Heatsink Material |
Aluminum Fins Copper Heatpipes |
Heatpipe |
Ø6mm x 7 pcs |
Fan Dimension |
140 x 140 x 25 mm ( L x W x H ) |
Fan quantity |
2 pcs |
Fan Speed |
PWM 500 ~ 1400 RPM With L.N.C PWM 300~1100 RPM |
Rated Voltage |
12V |
Start Voltage |
9V |
Rated Current |
0.17 A (one fan) |
Power Input |
2.04 W (one fan ) |
Air Flow |
81.96 CFM (one fan ) With L.N.C 65.03 CFM |
Static Pressure |
1.81 mm-H2O (one fan) With L.N.C 1.3 mm-H2O |
Acoustical Noise |
23.9 dB-A With L.N.C 18.5 dB-A |
Life time/Fan Life time |
40,000 hours |
Pin connect |
2510 - 4Pin |
Cooling Power |
250 W |
