Description
The TL-SG1024 Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 24 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1024 can save power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.
24 10/100/1000Mbps RJ45 ports
Innovative energy-efficient technology saves power consumption
Supports MAC address self-learning and auto MDI/MDIX
Standard 19-inch rack-mountable steel case
SPECIFICATIONS:
HARDWARE FEATURES |
|
Standards and protocols |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x |
Interface |
24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
Network media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m) |
Fan quantity |
Fanless |
Power supply |
100-240VAC, 50/60Hz |
Dimensions ( W x D x H ) |
17.3*7.1*1.7 in. (440*180*44 mm) |
Mounting |
Rack Mountable |
Max power consumption |
13.08W(220V/50Hz) |
Max heat dissipation |
44.63BTU/h |
PERFORMANCE |
|
Switching capacity |
48Gbps |
Packet forwarding rate |
35.7Mpps |
MAC address table |
8K |
Jumbo frame |
10KB |
QOS |
802.1p/DSCP QoS* *Only for V11 and later version |
Green technology |
Yes |
Transfer method |
Store-and-Forward |
OTHERS |
|
Certification |
FCC, CE, RoHS |
Package contents |
24-Port Gigabit Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
