Description
SPECIFICATIONS:
HARDWARE FEATURES |
|
Interface |
5× 10/100/1000Mbps RJ45 Ports AUTO Negotiation AUTO MDI/MDIX |
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m |
Fan Quantity |
Fanless |
External Power Supply |
External Power Adapter (Output: 53.5 VDC / 0.81 A) |
Packet Forwarding Rate |
7.44 Mpps |
PoE Ports (RJ45) |
Standard: 802.3 af/at compliant PoE Ports: Ports 1–4 Power Supply: 40 W |
Mac Address Table |
2K |
Jumbo Frame |
16 KB |
Switching Capacity |
10 Gbps |
Dimensions ( W x D x H ) |
3.9×3.9×1.0 in (99.8×98×25 mm) |
Max Power Consumption |
4.12 W (220/50 Hz. no PD connected) 47.5 W (220/50 Hz. with 40 W PD connected) |
Max Heat Dissipation |
14.05 BTU/h (no PD connected) 161.98 BTU/h (with 40 W PD connected) |
SOFTWARE FEATURES |
|
Advanced Features |
Compatible With IEEE 802.3af/at Compliant PDs Mac Address Auto-Learning And Auto-Aging IEEE 802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping |
Transfer Method |
Store-And-Forward |
OTHERS |
|
Certification |
FCC, CE, RoHS |
Package Contents |
TL-SG1005LP Power Adapter Installation Guide |
Environment |
Operating Temperature: 0–40 ℃ (32–104 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
Notes |
*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors. |
