TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+

Interface

8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port

AUTO Negotiation

AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Fan Quantity

Fanless

Physical Security Lock

Yes

External Power Supply

External Power Adapter (Output: 53.5VDC / 2.43A)

Packet Forwarding Rate

5.6544 Mpps

PoE Ports (RJ45)

Standard: 802.3 af/at compliant

PoE Ports: Ports 1–8

Power Supply: 124 W

Mac Address Table

2K

Jumbo Frame

16 KB

Switching Capacity

7.6 Gbps

Dimensions ( W x D x H )

8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)

Max Power Consumption

5.95 W (220/50 Hz. no PD connected)

140.92 W (220/50 Hz. with 124 W PD connected)

Max Heat Dissipation

20.29 BTU/h (no PD connected)

480.54 BTU/h (220/50 Hz. with 124 W PD connected)

SOFTWARE FEATURES

Transmission Method

Store-And-Forward

Advanced Functions

Compatible With IEEE 802.3af/at Compliant PDs

Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission)

Isolation Mode Button (Ports 1–8)

PoE Auto Recovery Button (Ports 1–8)

 Mac Address Auto-Learning and   Auto-Aging

IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode

OTHERS

Certification

FCC, CE, RoHS

Package Contents

TL-SL1311MP

Power Adapter

Installation Guide

Environment

Operating Temperature: 0–40 ℃ (32–104 ℉)

Storage Temperature: -40–70 ℃ (-40–158 ℉)

Operating Humidity: 10–90% RH non-condensing

Storage Humidity: 5–90% RH non-condensing
