Description
SPECIFICATIONS:
POWER |
|
AC adapter input |
100-240V ~ 50/60Hz 0.4A |
AC adapter output |
12V 1.2A |
HARDWARE FEATURES |
|
Processor |
Qualcomm CPU |
Interface |
2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit |
Button |
1 Reset button on the underside |
External Power Supply |
12 V/1.2 A |
Dimensions |
3.6 in. x 7.5 in. (90.7 mm x 190 mm) |
Antenna Type |
2 internal dual-band antennas per Deco unit |
WIRELESS FEATURES |
|
Wireless Standards |
IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz |
Frequency |
2.4 GHz and 5 GHz |
Signal Rate |
300 Mbps on 2.4 GHz 867 Mbps on 5 GHz |
Transmit Power |
FCC: <30 dBm |
Wireless Security |
WPA-PSK/WPA2-PSK |
Advanced Functions |
Router/ Access Point Mode Optional Ethernet Backhaul Guest network TP-Link Mesh Technology: MU-MIMO Auto Path Selection Self-Healing AP Steering Band Steering Beamforming |
SOFTWARE FEATURES |
|
Quality of Service |
WMM |
IPv6 |
Support |
WAN Type |
Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management |
Local Management, Remote Management |
DHCP |
Server, Client |
Port Forwarding |
Support |
Access Control |
Blacklist |
Firewall Security |
SPI Firewall |
Protocols |
Supports IPv4 and IPv6 |
Advanced Features |
Parental Controls Quality of Service |
Advanced Functions |
Monthly Reports Auto FW Update Expand Wi-Fi by adding more Deco units |
Guest Network |
2.4 GHz guest network x 1 5 GHz guest network x 1 |
Beamforming |
Support |
APP |
Easy setup via Deco App |
OTHERS |
|
Certification |
CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS |
Package Contents |
3 Deco units 1 RJ45 Ethernet Cable 3 power adapters 1 quick installation guide |
Smartphone/Tablet Requirements |
iOS 9.0 or later Android 4.3 or later |
Environment |
Operating Temperature: 0~40(32~104) Storage Temperature: -40~70(-40~158) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
