WIRELESS |
Standards |
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz |
WiFi Speeds |
AX1800
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax) |
WiFi Capacity |
High
Dual-Band
Distribute devices to different bands for optimal performance
MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple WiFi 6 clients
4 Streams
More than enough bandwidth for connected devices
|
Working Modes |
Router Mode
Access Point Mode |
HARDWARE |
Processor |
1.5 GHz Quad-Core CPU |
Performance |
Microphone
Quadruple microphone array
Speaker
5 W full frequency speaker with double bass passive diaphragm |
Ethernet Ports |
2× Gigabit Ports
*Per Deco Voice Unit
Supports WAN/LAN auto-sensing |
Buttons |
1 Reset Button
1 Mute Button
1 Action Button
2 Volume Buttons |
Power |
12 V ⎓ 1.5 A |
SECURITY |
WiFi Encryption |
WPA-Personal
WPA2-Personal
WPA3-Personal |
Network Security |
SPI Firewall
Access Control
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
|
Guest Network |
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
SOFTWARE |
Protocol |
IPv4
IPv6 |
Parental Controls |
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports
|
WAN Types |
Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
Quality of Service |
HomeShield QoS
QoS by Device
|
Cloud Service |
OTA Firmware Upgrade
TP-Link ID
DDNS |
NAT Forwarding |
Port Forwarding
UPnP |
IPTV |
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
DHCP |
Address Reservation
DHCP Client List
Server |
DDNS |
TP-Link |
Management |
Deco App |
PHYSICAL |
Dimensions (W×D×H) |
4.13 × 4.13 × 6.69 in
(105 × 105 × 170 mm) |
Package Contents |
Deco Voice X20 (1-pack)
1 Deco Voice X20 unit
1 RJ45 Ethernet cable
1 Power adapter
1 Quick Installation Guide
|
OTHERS |
System Requirements |
Android 4.4 or later
iOS 9.0 or later |
Certifications |
CE, EAC, FCC, IC, RoHS, RCM |
Environment |
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH |
TEST DATA |
WiFi Transmission Power |
CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm(2.4 GHz)
<30 dBm(5 GHz) |
