Description
SPECIFICATIONS:
GENERAL |
|
Processor |
Qualcomm 1 GHz Quad-core CPU |
Interface |
2 LAN/WAN Gigabit Ethernet Ports |
Button |
1 Reset button on the underside |
Dimensions |
Φ4.33 in. × 4.49 in. (Φ110 mm × 114 mm) |
Antenna |
4 internal antennas per Deco unit |
WIRELESS FEATURES | |
Wireless Standards |
IEEE 802.11 ax/ac/n/a 5 GHz, IEEE 802.11 ax/n/g/b 2.4 GHz |
Frequency |
5 GHz 2.4 GHz |
Signal Rate |
1201 Mbps (5 GHz) 574 Mbps (2.4 GHz) |
Transmit Power |
FCC: <30 dBm CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
Wireless Security |
WPA-PSK WPA2-PSK WPA3 |
Advanced Functions |
Router/ Access Point Mode Optional Ethernet Backhaul TP-Link Mesh Technology: MU-MIMO OFDMA 1024-QAM BSS Color Auto Path Selection Self-Healing AP Steering Band Steering Beamforming |
SOFTWARE FEATURES | |
Quality of Service |
WMM |
IPv6 |
Support |
WAN Type |
Dynamic IP/Static IP/PPPoE |
Management |
Local Management, Remote Management |
DHCP |
Server, Client |
Port Forwarding |
Support |
Access Control |
Blacklist |
Firewall Security |
SPI Firewall |
Protocols |
Supports IPv4 and IPv6 |
Advanced Features |
Homecare: Antivirus Parental Controls Quality of Service |
Advanced Functions |
Speedtest Monthly Usage Reports Auto FW Update Expand Coverage by Adding more decos |
Guest Network |
2.4 GHz guest network * 1 5 GHz guest network * 1 |
Beamforming |
Support |
APP |
Easy setup by Deco App |
OTHERS | |
Certification |
CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS |
Package Contents |
Deco X20 (3-pack): 3 Deco X20 units 1 RJ45 Ethernet Cable 3 Power Adapters 1 Quick Installation Guide |
Smartphone/Tablet Requirements |
iOS 9.0 or later Android 4.4 or later |
Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
