Description
SPECIFICATIONS:
WIRELESS |
|
Working Modes |
Range Extender/Access Point |
HARDWARE FEATURES |
|
Ports |
1× 2.5 Gbps Multi-Gig Port + 2× Gigabit Ports |
Button |
WPS Button, Reset Button |
Input Power |
100-240V~50/60Hz |
Power Consumption |
Max: 18W (with power adapter) |
Average: 9.2W |
|
Dimensions ( W x D x H ) |
7.4×2.3×7.9 in. (189×59×200 mm) |
Antenna |
Internal Antennas |
WIRELESS FEATURES |
|
Wireless Standards |
IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz |
Frequency |
2.4GHz and 5GHz |
Signal Rate |
1148 Mbps at 2.4 GHz, 4804 Mbps at 5 GHz |
Working Modes |
Range Extender/Access Point |
Reception Sensitivity |
5GHz: 11ax HE20 MCS0：-93dBm, 11ax HE20 MCS11：-62dBm 11ax HE40 MCS0：-90dBm, 11ax HE40 MCS11：-59dBm 11ax HE80 MCS0：-87dBm, 11ax HE80 MCS11：-56dBm 11ax HE160 MCS0：-84dBm, 11ax HE160 MCS11：-53dBm
2.4GHz: 11ax HE20 MCS0：-95dBm, 11ax HE20 MCS11：-64dBm 11ax HE40 MCS0：-92dBm, 11ax HE40 MCS11：-62dBm |
Wireless Functions |
LED Control, Access Control, Power Schedule, Wi-Fi Coverage |
Wireless Security |
WPA/WPA-PSK2 encryptions, WPA3 |
Transmission Power |
FCC: 2.4GHz < 30dBm, 5GHz < 30dBm, 6GHz < 30dBm |
Mesh Technology |
EasyMesh-Compatible |
OTHERS |
|
Certification |
FCC, RoHS |
Package Contents |
Wi-Fi Range Extender RE900XD Quick Installation Guide |
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
