TP-Link TL-POE10E Fast Ethernet PoE+ Extender
The Fast Ethernet PoE+ Extender TL-POE10E is designed to extend the data transmission distance between PoE power sourcing equipment and PoE powered devices. It can be used with 802.3af/at-compliant devices, which is very suitable for long-distance wiring requirements in surveillance scenarios.
2*10/100 Mbps ports
Compliance with 802.3af/at devices
Supplies up to 20 W, which meets the power consumption requirements of most IP cameras
Extends a PoE/PoE+ network connection an additional 100 m/250 m (10 Mbps mode) from the PoE power sourcing equipment
Plug-and-Play, requires no configuration
SPECIFICATIONS:
NETWORK |
|
Standards and Protocols |
IEEE802.3i, IEEE802.3u |
GENERAL |
|
Certification |
FCC, CE, RoHS |
Environment |
Operating Temperature: 0°C to 45°C (32°F to 113°F) Storage Temperature: -40°C to 70°C (-40°F to 158°F) Operating Humidity: 10% to 90%RH non-condensing Storage Humidity: 5% to 90%RH non-condensing |
Material |
Plastics Casing |
PACKAGE CONTENTS |
|
Package Contents |
Fast Ethernet PoE+ Extender TL-POE10E Installation Guide |
HARDWARE FEATURES |
|
Network Media |
UTP/STP of Cat.5E or above (based on the standards that the connected devices comply with) |
Ports |
1 10 Mbps /100 Mbps RJ45 PoE IN Port 1 10 Mbps /100 Mbps RJ45 PoE OUT Port |
Basic Function |
1 10/100Mbps RJ45 PoE IN port 1 10/100Mbps RJ45 PoE Out port, supplies up to 20 W Up to 250 m data and power transmitting range under 10Mbps mode Plug-and-Play |
Dimensions ( W x D x H ) |
2.33*0.85*0.52 in (71*26*16 mm) |
POE ADAPTER FEATURES |
|
Output |
Compliance with 802.3af/at devices |
