Description
SPECIFICATIONS:
CAMERA |
|
Image Sensor |
1/3” Progressive Scan CMOS Starlight Sensor |
Lens |
Focal Length: 4 mm Aperture: F2.0 Field of View: 88° (Diagonal), 75°(Horizontal), 41°(Vertical) |
Motion Range |
Pan Mechanical Range: 340° (360° Pan Coverage) Tilt Mechanical Range: 69° (110° Tilt Coverage) |
Night Vision |
850 nm IR LED (30 ft / 10 m) |
Interface & Button |
1× RESET Button 1× MicroSD Card Slot (Up to 512GB) |
VIDEO & AUDIO |
|
Maximum Resolution |
2K QHD 4MP (2560 x 1440px) |
Frame Rate |
15/20/25/30 fps (Default 15fps) |
Digital Zoom |
12x |
Video Compression |
H.264 |
Live View |
Yes |
Image Enhancement |
3D DNR WDR |
Audio Input & Output |
Built-in Microphone and Speaker |
Audio Communication |
Two-Way Audio with Noise Cancellation |
Siren Volume |
99dB (Level measured at 4-inch/10-cm distance) |
STORAGE |
|
Local Storage |
MicroSD Card Slot on Camera (Up to 512 GB)* |
Cloud Storage |
Tapo Care Cloud Storage Services (Subscription required)* |
DETECTION AND NOTIFICATIONS |
|
AI Detection |
Motion Detection Person Detection Line-Crossing Detection Tamper Detection BabyCry Detection Vehicle Detection Pet Detection Meow Detection Bark Detection Glass-Breaking Detection |
Activity Zones |
Yes |
Output Notification |
System Notification System Notification with Snapshot (Tapo Care Services) |
NETWORK |
|
Network Connectivity |
Connect via Wi-Fi |
Wireless Connectivity |
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
Ethernet Port |
/ |
RTSP |
Yes |
ONVIF |
Yes |
SECURITY |
|
Security |
On-Device Machine Learning 128-bit AES Encryption with SSL/TLS WPA/WPA2-PSK |
POWER |
|
Power Source |
9V DC Power Adapter |
Input Voltage |
100-240 V, 50/60 Hz |
Output Voltage |
9V, 0.6 A (DC Power) |
GENERAL |
|
Smart Integration |
Google Assistant, Amazon Alexa |
System Requirements |
Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher |
Mounting Options |
Tabletop Ceiling-Mounted |
Operating Temperature |
0℃~40℃ |
Storage Temperature |
-20℃~60℃ |
Operating Humidity |
10%~90% RH, Non-condensing |
Storage Humidity |
5%~90% RH, Non-condensing |
Dimensions |
3.36 × 3.42 × 4.63 in (85.4 × 86.8 × 117.7 mm) |
Package Contents |
TC72 Camera Power Adapter Quick Start Guide Mounting Screws Mounting Template Camera Base Mounting Anchors |
Notes |
* microSD Card purchased separately. * Tapo Care subscribe at: https://www.tapo.com |
