TP-Link VIGI NVR1008H 8 Channel Network Video Recorder

Decoding Format

H.265+/H.265/ H.264+/H.264

Live View/Playback Resolution

5 MP/ 4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Synchronous Playback

4 Channel

Capability

1-ch @ 5MP, 2-ch @ 2MP, 4-ch @ 720p

NETWORK

Protocol

TCP/IP, DHCP, DNS, NTP, UPnP

Incoming Bandwith

80 Mbps

Outgoing Bandwidth

60 Mbps

INTERFACES

Network Interface

1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface

USB Interface

2× USB 2.0

HARD DISK

SATA

1 SATA Interface

Capacity

Up to 10 TB

GENERAL

Package Contents

VIGI Network Video Recorder

Power Adapter

HDD Screws

Quick Installation Guide

Operating Temperature

-10–55 °C

Dimensions( W X D X H )

246.2 × 148.2 × 45 mm

Weight

578.5 g

External Power Supply

DC 12V/1.5A

Power Consumption

4.25 W (without disk)

VIDEO/IMAGE

Video Input

8-Channel IP Video Input, up to 5 MP Resolution

Video Output

Recording Resolution: 5 MP/ 4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

HDMI/VGA

Output Resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1680 × 1050/60Hz, 1440 × 900/60Hz

OTHERS

Notes

+Fewer or no channels may be available for playback if the total resolution is greater than 5MP.

HDD is not included.

△A hard disk drive (not included) must be installed for operation.

*Calculations based on laboratory testing using a 3MP VIGI camera. Actual performance may vary according to the amount of activity recorded, resolution, and other variables.

**VIGI NVR works best with VIGI cameras but is compatible with other brands.
