TP-Link VIGI NVR1008H-8P 8 Channel PoE+ Network Video Recorder

Decoding Format

H.265+/H.265/ H.264+/H.264

Live View/Playback Resolution

8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Synchronous Playback

8 Channel

Capability

2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP

NETWORK

Protocol

TCP/IP, DHCP, DNS, NTP, UPnP

Incoming Bandwidth

80 Mbps

Outgoing Bandwidth

60 Mbps

INTERFACES

Network Interface

1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface

USB Interface

2× USB 2.0

HARD DISK

SATA

1 SATA Interface

Capacity

Up to 10 TB

GENERAL

Package Contents

VIGI Network Video Recorder

Power Adapter

HDD Screws

Quick Installation Guide

Operating Temperature

-10–55 °C

Dimensions( W X D X H)

294 × 180 × 44 mm

PoE

Standard: 802.3af/at

PoE Ports: Ports 1-8

PoE Budget: 53 W

External Power Supply

53.5V DC/1.31 A

Power Consumption

2.38 W (without disk)

12.94 W (with disk)

VIDEO/IMAGE

Video Input

8-Channel IP Video Input, up to 8 MP Resolution

Recording Resolution

8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

HDMI Output Resolution

1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz

VGA Output Resolution

1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz

OTHERS

Notes

Rack-mounting accessories are not included.

Calculations based on laboratory testing using VIGI cameras.

^§PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.

^△Some features may operate sub-optimally due to compatibility issues. For best performance, we recommend using VIGI NVR with VIGI cameras.

^*Fewer or no channels may be available for playback if the total resolution is 16MP.

^**Calculations based on laboratory testing using a 3MP VIGI camera. Actual performance may vary according to the amount of activity recorded, resolution, and other variables.
