Description
SPECIFICATIONS:
WIRELESS |
|
Standards |
Wi-Fi 6E IEEE 802.11ax 6 GHz IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
WiFi Speeds |
AXE5400 6 GHz: 2402 Mbps (802.11ax, HE160) 5 GHz: 2402 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax) |
WiFi Range |
1-3 Bedroom Houses (1-pack) TP-Link Mesh Technology Optional Ethernet backhaul work together to link Deco units to provide seamless coverage AI-Driven Mesh Intelligently learns the network environment to provide ideal Wi-Fi unique to your home 4× High-Gain Antennas (Internal) Multiple antennas form a signal-boosting array to cover more directions and large areas Tri-Band A newly-opened 6 GHz band brings more bandwidth and faster speeds Beamforming Concentrates wireless signal strength towards clients to expand WiFi range |
WiFi Capacity |
Very High Tri-Band Distribute devices to different bands for optimal performance 2×2 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple WiFi 6 clients 6 Streams More than enough bandwidth for connected devices |
Working Modes |
Router Mode Access Point Mode |
HARDWARE |
|
Processor |
1.7 GHz Quad-Core CPU |
Ethernet Ports |
1× 2.5 Gbps Port + 2× Gigabit Ports *Per Deco Unit Supports WAN/LAN auto-sensing |
Buttons |
Reset Button |
SECURITY |
|
WiFi Encryption |
WPA-Personal WPA2-Personal WPA3-Personal |
Network Security |
SPI Firewall Access Control
HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner |
Guest Network |
1× 6 GHz Guest Network 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
SOFTWARE |
|
Protocols |
IPv4 IPv6 |
Service Kits |
HomeShield |
Parental Controls |
HomeShield Parental Controls Custom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports |
WAN Types |
Dynamic IP Static IP PPPoE PPTP L2TP |
Quality of Service |
HomeShield QoS QoS by Device |
Cloud Service |
OTA Firmware Upgrade TP-Link ID DDNS |
NAT Forwarding |
Port Forwarding UPnP |
IPTV |
IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP |
Address Reservation DHCP Client List Server |
DDNS |
TP-Link |
Management |
Deco App |
PHYSICAL |
|
Dimensions (W×D×H) |
4.1 × 4.1 × 6.7 in (105 × 105 × 169 mm) |
Package Contents |
Deco XE75 Pro (1-pack) 1 Deco XE75 Pro units 1 RJ45 Ethernet cable 1 Power adapters 1 Quick Installation Guide |
OTHERS |
|
Certifications |
CE, FCC, RoHS |
Environment |
Operating Temperature: 0°C~40°C (32 °F~104 °F) Storage Temperature: -40°C~60°C (-40 °F~140 °F) Operating Humidity: 10%~90% RH Storage Humidity: 5%~90% RH |
TEST DATA |
|
WiFi Transmission Power |
CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) <23 dBm (6 GHz)
FCC: <30 dBm (2.4 GHz) <30 dBm(5 GHz) <30 dBm(6 GHz) |
