Description
SPECIFICATIONS:
Dimensions |
94 × 60 × 33 mm (3.70 × 2.36 × 1.30") |
Weight |
156 g (5.5 oz) |
Output voltage |
24VDC @ 1.25A |
LAN activity indicator |
No |
Gigabit LAN port |
Yes |
Remote reset capability |
No |
Reset button |
No |
Rated voltage |
100-240V AC @ 50/60Hz |
Input current |
0.6A @ 120VAC, 0.4A @ 240VAC |
Inrush current |
<60A Peak @ 120VAC, <120A Peak @ 230VAC |
Efficiency |
83+% |
Output ripple |
1% Max. |
Switching frequency |
65 kHz |
Line regulation |
≤ 3% |
Load regulation |
≤ 5% |
4-pair powering |
Pins 1, 2, 4, 5 (+) and Pins 3, 6, 7, 8 (- |
Storage temperature |
-30 to 70°C (-22 to 158° F) |
Ambient operating temperature |
0 to 40° C (32 to 104° F) |
Ambient operating humidity |
35 to 95% noncondensing |
AC connector |
IEC-320 C6 |
Data IN / PoE |
RJ45 shielded socket |
Surge protection |
Difference and common mode |
Clamping protection |
11V data, 60V power |
Max. surge discharge |
1500A (8/20 μs) power |
Peak pulse current |
36A (10/1000 μs) data |
Shunt capacitance |
<5 pF data |
Response time |
<1 ns |
Certifications |
CE, FCC, IC, UL |
