Ubiquiti 48-port Layer 3 switch with 2.5 GbE PoThe Switch Enterprise

Dimensions

442 x 400 x 44 mm (17.4 x 15.7 x 1.7")

Weight

Without mounting brackets: 6.2 kg (13.7 lb)
With mounting brackets: 6.3 kg (13.9 lb)

Enclosure material

SGCC steel

HARDWARE

Management interface

Ethernet In-Band

Networking interface

(48) 2.5 GbE RJ45 ports
(4) 1/10G SFP+ ports

PoE interface

(48) PoE/PoE+ (Pins 1, 2+; 3, 6-)

Total non-blocking throughput

160 Gbps

Switching capacity

320 Gbps

Forwarding rate

238.095 Mpps

Power method

(1) Universal input, 100—240V AC, 10A Max., 50/60 Hz
(1) USP-RPS DC input, 52V DC, 13.84A; 11.5V DC, 13A

Power supply

AC/DC, internal, 100—240V, 10A Max.

Supported voltage range

100—240V AC

Max. power consumption

150W (Excluding PoE output)

Total available PoE

720W

Max. PoE wattage per port by PSE

PoE+: 34.2W

Voltage range PoE mode

PoE: 44—57V
PoE+: 50—57V

Services

SMB Layer 3 PoE GbE Switch

ESD/EMP protection

Air: ± 16kV, contact: ± 12kV

LCM display

(1) 1.3" color touchscreen

Button

Factory reset

Operating temperature

-5 to 40° C (23 to 104° F)

Operating humidity

10 to 90% noncondensing

Certifications

CE,   FCC, IC

LEDS

System

Status

Ethernet

Link/activity

SFP+

Link/activity

APPLICATION REQUIREMENTS

UniFi Network

Version   6.2.26 and later
