Description
SPECIFICATIONS:
MECHANICAL |
|
Dimensions |
200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
Weight |
2.4 kg (5.29 lb) |
Enclosure material |
Polycarbonate |
Mount material |
Polycarbonate |
HARDWARE |
|
Management interface |
Ethernet In-Band |
Networking interface |
(8) 2.5 GbE, PoE+ RJ45 ports (2) 10G SFP+ |
PoE interface |
(8) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
Total non-blocking throughput |
40 Gbps |
Switching capacity |
80 Gbps |
Forwarding rate |
59.52 Mpps |
Power method |
(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz |
Power supply |
AC/DC, internal, 150W |
Supported voltage range |
100—240V AC |
Max PoE power |
120W |
Max. PoE+ wattage per port by PSE |
32W |
Voltage range PoE mode |
PoE: 44—57V PoE+: 50—57V |
LCM Display |
(1) 1.3" color touchscreen |
Mounting |
Desktop-mountable (Do not physically stack the USW-Enterprise-8-PoE.) |
ESD/EMP protection |
Air: ± 16kV, contact: ± 12kV |
Operating temperature |
-5 to 45° C (23 to 113° F) |
Operating humidity |
10 to 90% noncondensing |
Certifications |
CE, FCC, IC |
LEDS |
|
System |
Status |
Ethernet |
Link/activity |
SFP+ |
Link/activity |
APPLICATION REQUIREMENTS |
|
UniFi Network |
Version 6.3.51 and later |
