Description
SPECIFICATIONS:
Cable Length |
30m |
Connector type |
LC-LC |
Fiber mode |
OS2 |
Fiber type |
Duplex |
Polish |
UPC to UPC |
Wavelength |
1310/1550 nm |
Cable jacket material |
Low smoke zero halogen (LSZH) |
Jacket OD |
2.0 mm |
Jacket color |
Yellow |
Insertion loss |
≤ 0.3 dB |
Return loss |
≥ 50 dB |
Repeatability |
≤ 0.1 dB |
Durability |
≤ 0.2 dB (1,000 times mating) |
Ambient operating temperature |
-40 to 75° C (-40 to 167° F) |
