Description
SPECIFICATIONS:
MECHANICAL |
|
Dimensions |
442 x 325 x 44 mm (17.4 x 12.8 x 1.7") |
Weight |
Without mounting brackets: 4.6 kg (10.1 lb) |
Enclosure material |
SGCC steel |
HARDWARE |
|
Management interface |
Ethernet In-Band |
Networking interface |
(28) 1/10G SFP+ ports *The four SFP28 ports don't support mixed speed at 25 Gbps mode. Once one of the SFP28 ports is configured at 25 Gbps mode, the others will be limited at 25 Gbps too. The SFP28 ports only support mixed speed when all ports are at 1 Gbps or 10 Gbps. |
Total non-blocking throughput |
380 Gbps |
Switching capacity |
760 Gbps |
Forwarding rate |
565.44 Mpps |
Power method |
(1) Universal input, 100—240V AC, 2A Max., 50/60 Hz |
Power supply |
AC/DC, internal, 100W |
Supported voltage range |
100—240V AC |
Max. power consumption |
100W |
ESD/EMP protection |
Air: ± 16kV, contact: ± 12kV |
Services |
SMB Layer 3 10/25 G Fiber switch |
LCM display |
(1) 1.3" LCM color touchscreen |
Operating temperature |
-5 to 40° C (23 to 104° F) |
Operating humidity |
10 to 90% noncondensing |
Certifications |
CE, FCC, IC |
LEDS |
|
System |
Status |
SFP28/SFP+ |
Link/activity |
APPLICATION REQUIREMENTS |
|
UniFi Network |
Version 6.1.25 and later |
