Description
SPECIFICATIONS:
MECHANICAL |
|
Dimensions |
325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7") |
Weight |
2.1 kg (4.6 lb) |
Enclosure material |
SGCC steel |
HARDWARE |
|
Management interface |
Ethernet In-Band |
Networking interface |
(12) GbE RJ45 ports (4) 1/2.5 GbE RJ45 ports (2) 10G SFP+ ports |
PoE interface |
(12) PoE/PoE+ (Pins 1, 2+; 3, 6-) (4) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
Total non-blocking throughput |
42 Gbps |
Switching capacity |
84 Gbps |
Forwarding rate |
62.496 Mpps |
Power method |
DC adapter |
Power supply |
54V, 210W |
Max. power consumption |
30W (Excluding PoE output) |
Total available PoE |
180W |
Max. PoE wattage per port by PSE |
PoE: 15.4W PoE+: 30W PoE++: 60W |
Voltage range PoE mode |
PoE: 44—57V PoE+/PoE++: 50—57V |
LCM display |
(1) 1.3" touchscreen |
Button |
Factory reset |
Ambient operating temperature |
-5 to 40° C (23 to 104° F) |
Ambient operating humidity |
10 to 90% noncondensing |
Certifications |
CE, FCC, IC |
SWITCHING FEATURES |
|
Layer 2 features |
IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
Layer 3 features |
DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs |
ETHERLIGHTING™ |
|
Ethernet |
Locating Speed/link Native VLAN/network |
SFP+ |
Locating Speed/link Native VLAN/network |
