Description
SPECIFICATIONS:
OVERVIEW |
|
Dimensions |
203 x 76 x 33 mm (8 x 3 x 1.3") |
|
Port Layout 1 GbE RJ45 |
8 (7 PoE+; 1 PoE++ input) |
Max. PoE Output |
Up to PoE+ |
Total PoE Availability |
PoE++ input: 42W PoE+ input: 16W 60W PoE adapter input: 42W 60W AC adapter input: 52W 210W AC adapter input: 202 |
Form Factor |
Compact desktop, wall, magnetic |
PERFORMANCE |
|
Switching Capacity |
16 Gbps |
Total Non-Blocking Throughput |
8 Gbps |
Forwarding Rate |
12 Mpps |
Supported VLANs |
256 |
MAC Address Table Size |
4,000 |
LAYER 2 FEATURES |
|
STP & RSTP |
✓ |
Egress Rate Limit |
✓ |
Flow Control |
✓ |
Storm Control |
✓ |
Multicast & Broadcast Rate Limiting |
✓ |
Port Isolation |
✓ |
Port Mirroring |
✓ |
Jumbo Frames |
✓ |
Loop Protection |
✓ |
HARDWARE |
|
|
PoE Ports PoE+ PoE++ |
7 1 |
|
Max. PoE Wattage per Port by PSE PoE+ |
30W |
Max. Power Consumption |
9W (Excluding PoE Output) with PoE input 8W (Excluding PoE Output) with adapter input 210W (Including PoE Output) with 210W AC adapter input |
Power Method |
(1) AC/DC adapter (Included) (1) PoE++ |
Power Input Method |
DC Input PoE |
Power Supply |
AC/DC, external, 60W |
Supported Voltage Range |
50—57V DC/PoE |
Management |
Ethernet |
Heat Dissipation (Excluding PoE Output) |
30.708 BTU/hr 27.296 BTU/hr |
Weight |
Device: 320 g (11.3 oz) Wall mount: 45 g (1.6 oz) Adapter: 330 g (11.6 oz) |
Enclosure Material |
Polycarbonate |
Ambient Operating Temperature |
PoE++ input: -30 to 60° C (-22 to 140° F) 60W AC adapter input: -20 to 45° C (-4 to 113° F) |
Ambient Operating Humidity |
10 to 90% noncondensing |
Certifications |
CE, FCC, IC |
