Description
SPECIFICATIONS:
OVERVIEW |
|
Dimensions |
442 x 200 x 44 mm (17.4 x 7.9 x 1.7") |
Port Layout |
1 GbE RJ45: 16 (8 PoE+) (1G/100M/10M) 1G SFP: 2 (1G) |
Max. PoE Output |
Up to PoE+ |
Total PoE Availability |
42W |
Form Factor |
Rack mount (1U) |
PERFORMANCE |
|
Switching Capacity |
36 Gbps |
Total Non-Blocking Throughput |
18 Gbps |
Forwarding Rate |
27 Mpps |
Supported VLANs |
1,000 |
MAC Address Table Size |
8,000 |
Packet Buffer Size |
0.5 MB |
Access Lists |
IPv4: 128 MAC: 128 |
LAYER 2 FEATURES |
|
LACP Port Aggregation |
✓ |
STP & RSTP |
✓ |
Advanced IGMP Configuration |
✓ |
IGMP Snooping |
✓ |
802.1X Control |
✓ |
MAC-Based ACLs & Device Isolation |
✓ |
DHCP Snooping & Guarding |
✓ |
Egress Rate Limit |
✓ |
Flow Control |
✓ |
Storm Control |
✓ |
Multicast & Broadcast Rate Limiting |
✓ |
MAC Address Blocking |
✓ |
IP-Based ACLs & Network Isolation |
✓ |
MAC-Based Port Restriction |
✓ |
Port Isolation |
✓ |
Port Mirroring |
✓ |
Jumbo Frames |
✓ |
LLDP-MED |
✓ |
Voice VLAN |
✓ |
Loop Protection |
✓ |
HARDWARE |
|
PoE Ports |
PoE+: 8 |
Max. PoE Wattage per Port by PSE |
PoE: 15.4W PoE+: 32W |
Max. Power Consumption |
18W (Excluding PoE Output) 60W (Including PoE Output) |
Power Method |
Universal input, 100—240V AC, 50/60 Hz |
Power Input Method |
AC input |
Power Supply |
AC/DC, internal, 60W |
Supported Voltage Range |
100—240V AC |
Management |
Ethernet AR |
Heat Dissipation (Excluding PoE Output) |
61.416 BTU/hr |
Weight |
Without mounting brackets: 2.8 kg (6.2 lb) |
Enclosure Material |
SGCC steel |
Mount Material |
SGCC steel |
Supported Rack Depth |
400~1200 mm (15.7-47.2") |
LCM Display |
1.3" touchscreen |
ESD/EMP Protection |
Air: ± 16kV, contact: ± 12kV |
Ambient Operating Temperature |
-5 to 40° C (23 to 104° F) |
Ambient Operating Humidity |
10 to 90% noncondensing |
NDAA Compliant |
✓ |
Certifications |
CE, FCC, IC, Anatel |
SOFTWARE |
|
Application Requirements |
UniFi Network: Version 7.2.94 and later |
