Description
SPECIFICATIONS:
OVERVIEW |
|
Dimensions |
325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7") |
|
Port Layout 1 GbE RJ45 2.5 GbE RJ45 10G SFP+ |
12 4 2 |
Layer 3 |
✓ |
Form Factor |
Rack mount (1U), desktop, wall |
Etherlighting™ |
✓ |
PERFORMANCE |
|
Switching Capacity |
84 Gbps |
Total Non-Blocking Throughput |
42 Gbps |
Forwarding Rate |
62 Mpps |
Supported VLANs |
1,000 |
MAC Address Table Size |
16,000 |
|
L3 Table Size ARP Entries IPv4 Routes |
6,000 512 |
Packet Buffer Size |
1.5 MB |
LAYER 3 FEATURES |
|
DHCP Server (Local Networks) |
✓ |
DHCP Relay |
✓ |
Inter-VLAN Routing (Local Networks) |
✓ |
Static Routing (Local Networks) |
✓ |
LAYER 2 FEATURES |
|
LACP Port Aggregation |
✓ |
STP & RSTP |
✓ |
QoS (DSCP) |
✓ |
Pro AV Profiles |
✓ |
Advanced IGMP Configuration |
✓ |
IGMP Snooping |
✓ |
802.1X Control |
✓ |
MAC-Based ACLs & Device Isolation |
✓ |
DHCP Snooping & Guarding |
✓ |
Egress Rate Limit |
✓ |
Flow Control |
✓ |
Storm Control |
✓ |
Multicast & Broadcast Rate Limiting |
✓ |
MAC Address Blocking |
✓ |
IP-Based ACLs & Network Isolation |
✓ |
MAC-Based Port Restriction |
✓ |
Port Isolation |
✓ |
Port Mirroring |
✓ |
Jumbo Frames |
✓ |
LLDP-MED |
✓ |
Voice VLAN |
✓ |
Loop Protection |
✓ |
HARDWARE |
|
Max. Power Consumption |
25W |
Power Method |
AC/DC Adapter (included) |
Power Input Method |
USB Type-C, 5V DC, 5A |
Power Supply |
AC/DC, external, 25W |
Supported Voltage Range |
4.8—5.2V DC/USB |
Management |
Ethernet AR |
Heat Dissipation (Excluding PoE Output) |
85.3 BTU/hr |
Weight |
1.95 kg (4.3 lb) |
Enclosure Material |
SGCC steel |
LCM Display |
1.3" touchscreen |
Ambient Operating Temperature |
-5 to 40° C (23 to 104° F) |
Ambient Operating Humidity |
10 to 90% noncondensing |
Certifications |
CE, FCC, IC |
|
Etherlighting™ Ethernet SFP+ |
✓ ✓ |
