Network Video Recorder
The Network Video Recorder is a business-grade network video recorder that provides data redundancy and long-term storage capabilities.
 The UniFi® NVR is an enterprise network video recorder that integrates an NVR, the UniFi Protect software, and a 4-drive bay. The UNVR unifies enterprise-class data protection and scalable storage with simple plug and play integration using the intuitive UniFi Protect software. The drive bays are easily accessed from the front panel, so hard drive mounting and maintenance are simple. Using four 8 TB drives in a RAID 5 configuration, the UNVR can provide up to 30 days of 4k video storage for 15 cameras or Full HD video storage for 50 cameras.  Features:
Note: Please ensure your HDDs meet Ubiquiti's general guidelines and aren't included in their list of incompatible models. Simply Scalable Building Video SecurityThe platform designed for multi-camera deployments.  4x HDD Bay
2.5”/3.5” Drive Bay
 10 Gbps SFP+
10 Gbps SFP+ Port
 1 Gbps RJ45
Gigabit RJ45 Port
 Plug & Play System
UniFi Protect System with NVR
 RAID 1 or RAID 5
Automated secure
RAID 1 or RAID 5 configuration  Redundant Power
Redundant Power Support
Store your Footage for 30 DaysEnterprise network video recorder, can provide up to 30 days of 4K video storage for 15 cameras or Full HD video storage for 50 cameras.
Redundant Power SupportProprietary redundant power system designed to protect from sudden power supply module failure. Use USP-RPS* or USW-Mission-Critical*. * Sold separately
Automized Secure RAID 1/5 ConfigurationThe UNVR unifies enterprise-class data protection and scalable storage with simple Plug and Play integration using the intuitive UniFi Protect software. Low Quality
Normal Quality
Best Quality
Storage for 58 days
Minimum 40 days of continuous motion recording* *Storage and continuous recording times based on 10x 4K Cameras and 10x HD Cameras.
Know more about your Network than ever beforeKeep an eye on your property from any device from anywhere.
SPECIFICATIONS
Mechanical
Dimensions
442.4 x 325 x 43.7 mm Weight
Without Rackmount Brackets: 5.11 kg Enclosure Material
SGCC Steel Hardware
Processor
Quad-Core ARM® Cortex®-A57 at 1.7 GHz System Memory
4 GB On-Board Flash Storage
8 GB Max. Power Consumption
100W Max. Power Budget for Drives
75W Power Method
(1) Universal AC input, 100-240VAC, 2A Max, 50/60 Hz Power Supply
AC/DC, Internal, 120W Networking Interfaces
(1) 10/100/1000 Mbps RJ45 Ethernet Management Interface
Ethernet In-Band Management ESD/EMP Protection
Air: ± 12kV, Contact: ± 8kV Operating Temperature
-5 to 40° C Operating Humidity
5 - 95% Noncondensing Certifications
FCC, CE, IC LEDs
System
(1) Power, Blue/White Ethernet
Green: 1000 Mbps, Amber: 10/100 Mbps SFP+
White: 10 Gbps, Green: 1 Gbps HDD
Amber: Disk Error, White: Disk Detected RPS
Blue: Ready |
Description
|
Product Name: Ubiquiti UniFi Protect Network Video Recorder (UNVR)
|
|
Model Number: UNVR
|
|
Brand: Ubiquiti
|
| Manufacturer Warranty: 1 Year |
