The UNVR Pro is a UniFi OS Console that runs the pre-installed UniFi Protect application and has a 7-drive hard disk drive (HDD) bay that offers the greatest storage capacity of any UniFi OS Console. The powerful, easy-to-use UNVR Pro can be deployed in minutes and support systems with up to 60 cameras. Combining the best features of Cloud and onsite surveillance systems, UniFi Protect gives you centralized, local, low-latency access to all of your live camera feeds and recordings, as well as remote access from anywhere in the world via unifi.ui.com and the Protect mobile app.
The UNVR Pro also offers expanded RAID configuration options for enhanced data protection, applying either RAID 1, 5, or 10 based on the number of HDDs installed. It's also equipped with a 1.3" touchscreen display for concise, convenient video event previewing.*
- (7) 2.5"/3.5" HDD bays
- (1) 10G SFP+ port
- (1) GbE RJ45 port
- 2U-sized, rack-mountable console (kit Included)
- 1.3" touchscreen with video event previewing*
- Pre-installed UniFi Protect application
- Simple, Bluetooth-powered setup via the UniFi Protect mobile app
- Automated RAID 1, 5, or 10 HDD configuration
- Connect a SmartPower Redundant Power System to create an uninterruptible network
Note: Please ensure your HDDs meet Ubiquiti's general guidelines and aren't included in their list of incompatible models.
*Will be included in a future console update
Optimize your camera security
The UNVR Pro is designed to support the most demanding, multi-camera systems.
Ample HD and 4K video storage
Access high-resolution recordings when you need them.
Reclaim your power
Stay operational through sudden power failure by connecting to the USP RPS* or Switch Mission Critical*
See how long you can store your footage
Storage duration will vary based on camera count and preferred image quality. Use the tool below to approximate yours.
Storage for
42 days of continuous motion
More ways to monitor what matters most
Instantly view live feeds, access recordings, and manage your cameras with UniFi Protect.
442 x 325 x 87 mm
Without Rackmount Brackets: 9.2 kg
With Rackmount Brackets: 9.45 kg
SGCC Steel
SGCC Steel
160W
135W
(1) Universal AC input, 100-240VAC, 3A Max, 50/60 Hz
(1) USP-RPS DC input, 11.5VDC, 13.91A
AC/DC, Internal, 200W
(1) 10/100/1000 Mbps RJ45 Ethernet
(1) 1/10 Gbps SFP+ Ethernet
(1) Bluetooth v4.1
(1) 1.3" Touchscreen
Bootup Animation: Bootup in Progress
Firmware Upgrade Icon: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
Ethernet In-Band Management
Air: ± 12kV, Contact: ± 8kV
-5 to 40° C
5 - 95% Noncondensing
FCC, CE, IC
White: 10/100/1000 Mbps
White: 1/10 Gbps
Amber: Disk Error, White: Disk Detected
Blue: Ready
