Description
SPECIFICATIONS:
OVERVIEW |
|
Dimensions |
122.5 x 107.1 x 28 mm (4.8 x 4.2 x 1.1") |
|
Port Layout 1 GbE RJ45 |
5 (4 PoE+; 1 PoE++) |
Max. PoE Output |
Up to PoE+ |
Total PoE Availability |
46W |
Form Factor |
Compact desktop, wall, pole |
PERFORMANCE |
|
Switching Capacity |
10 Gbps |
Total Non-Blocking Throughput |
5 Gbps |
Forwarding Rate |
7 Mpps |
Supported VLANs |
1,000 |
MAC Address Table Size |
2,000 |
LAYER 2 FEATURES |
|
Egress Rate Limit |
✓ |
Flow Control |
✓ |
Port Isolation |
✓ |
Port Mirroring |
✓ |
Jumbo Frames |
✓ |
HARDWARE |
|
|
PoE Ports PoE+ PoE++ |
4 1 |
|
Max. PoE Wattage per Port by PSE PoE+ |
25W |
Max. Power Consumption |
5W (Excluding PoE Output) 51W (Including PoE Output) |
Power Method |
PoE++ |
Power Input Method |
PoE |
Supported Voltage Range |
50—57V PoE |
Management |
Ethernet |
Heat Dissipation (Excluding PoE Output) |
17.06 BTU/hr |
Weight |
230 g (8.1 oz) |
Ambient Operating Temperature |
46W PoE output: -40 to 55° C (-40 to 131° F) 25W PoE output: -40 to 65° C (-40 to 149° F) |
ESD/EMP Protection |
Air/contact: ± 16kV |
Ambient Operating Humidity |
5 to 95% noncondensing |
Certifications |
CE, FCC, IC |
