Description
SPECIFICATIONS:
MECHANICAL |
|
Dimensions |
343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4") |
Weight |
819 g (1.8 lb) |
Enclosure material |
UV-stabilized polycarbonate |
Mount material |
Aluminum alloy, steel |
Pole mount diameter |
1~2.5" on pipe outer diameter |
Weatherproofing |
IPX6 |
HARDWARE |
|
Networking interface |
(2) GbE RJ45 ports |
Management interface |
Ethernet WiFi |
Power method |
PoE |
Power supply |
UniFi PoE switch 48V, 0.5A PoE adapter (Included) |
Supported voltage range |
42.5—57V DC |
Max. power consumption |
9W |
|
Max. TX power 2.4 GHz 5 GHz 6 GHz |
22 dBm 27 dBm – |
|
MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 (DL/UL MU MIMO) 2 x 2 (DL/UL MU-MIMO) – |
|
Max. data rate 2.4 GHz 5 GHz 6 GHz |
573.5 Mbps (BW40) 2.4 Gbps (BW160) – |
|
Antenna gain 2.4 GHz 5 GHz 6 GHz |
8 dBi 8 dBi – |
LEDs |
White/blue |
Button |
Factory reset |
Mounting |
Wall, pole (Included) |
Ambient operating temperature |
-30 to 60° C (-22 to 140° F) |
Ambient operating humidity |
5 to 95% noncondensing |
Certifications |
CE, FCC, IC |
SOFTWARE |
|
WiFi standards |
802.11a/b/g/n/ac/ax (WiFi 6) |
Wireless security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
BSSID |
8 per radio |
VLAN |
802.1Q |
Advanced QoS |
Per-user rate limiting |
Guest traffic isolation |
Supported |
Concurrent clients |
250+ |
SUPPORTED DATA RATES |
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b |
1, 2, 5.5, 11 Mbps |
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15 , HT 20/40) |
802.11ac |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
802.11ax (WiFi 6) |
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
APPLICATION REQUIREMENTS |
|
UniFi Network |
Version 8.1.127 and later |
