Description
Compatible with 7mm and 9.5mm 2.5″ SATA HDD/SSD up to 4TB
SuperSpeed USB 3.0 Interface, backwards compatible with USB 2.0/1.1
The durable Aluminium-alloy material promises effective heat dissipation
Easy installation allow to mount Hard Drive in seconds
Hot-swapping, plug and play, no additional driver needed
LED light indicates power and activity status
Compatible with Windows XP and above, Linux, Mac OS 10.4 and above
SPECIFICATIONS:
HARDWARE | |
Chipset ID |
VL716 |
Compatible Drive Types |
SATA |
Drive Installation |
Fixed |
Drive Size |
2.5in |
Fan(s) |
No |
Number of Drives |
1 |
PERFORMANCE | |
Max Drive Capacity |
Currently tested with up to 4TB 7200 RPM hard drives |
RAID |
No |
Type and Rate |
USB 3.0 – 5 Gbit/s |
UASP Support |
Yes |
CONNECTOR(S) | |
Drive Connectors |
1 – SATA Data & Power Combo (7+15 pin) Receptacle |
Host Connectors |
1 – USB 3.0 Micro-B (10 pin, SuperSpeed) Female |
SOFTWARE | |
OS Compatibility |
OS independent; No software or drivers required |
INDICATORS | |
LED Indicators |
1 – Power & Activity |
POWER | |
Power Source |
USB-Powered |
ENVIRONMENTAL | |
Humidity |
10%RH ~ 95%RH |
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
Storage Temperature |
-10°C to 65°C (14°F to 149°F) |
PHYSICAL CHARACTERISTICS | |
Color |
Black |
Enclosure Type |
Aluminium |
Max Drive Height |
9.5 mm |
WHAT’S IN THE BOX | |
Included in Package |
1 – USB 3.0 to 2.5″ SSD/HDD Enclosure 1 – USB 3.0 Cable 1 – Screw driver 1 – Install Guide |
