Description
SPECIFICATIONS:
HARDWARE | |
Chipset ID |
JMS578 |
Compatible Drive Types |
SATA |
Drive Installation |
Fixed |
Drive Size |
3.5” |
Fan(s) |
No |
Interface |
USB 3.0 |
Number of Drives |
1 |
PERFORMANCE | |
Max Drive Capacity |
Currently tested with up to 8TB 7200 RPM hard drive |
RAID |
No |
Type and Rate |
USB 3.0 – 5 Gbit/s |
UASP Support |
Yes |
CONNECTOR(S) | |
Drive Connectors |
1 – SATA Data & Power Combo (7+15 pin) Receptacle |
Host Connectors |
1 -USB 3.0 Female |
SOFTWARE | |
OS Compatibility |
OS independent; No software or drivers required |
SPECIAL NOTES / REQUIREMENTS | |
System and Cable Requirements |
Available USB port |
INDICATORS | |
LED Indicators |
1 – Power & Activity |
POWER | |
Centre Tip Polarity |
Positive |
Input Current |
0.6 A |
Input Voltage |
100 ~ 240 AC |
Output Current |
2 A |
Output Voltage |
12 DC |
Power Consumption (In Watts) |
24 |
Power Source |
AC Adapter Included |
ENVIRONMENTAL | |
Humidity |
Operation Humidity: 10% ~ 90% RH |
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
Storage Temperature |
-10°C to 65°C (14°F to 149°F) |
PHYSICAL CHARACTERISTICS | |
Colour |
Black |
Enclosure Type |
Aluminium |
Product Height |
115mm |
Product Length |
185mm |
Product Width |
33mm |
Product Weight |
350g |
PACKAGING INFORMATION | |
Shipping (Package) Weight |
0.8kg |
