Description
SPECIFICATIONS:
HARDWARE |
|
Bus Type |
USB 3.1 Gen 2 (10Gbps) |
Chipset ID |
VL822+RTL8153 |
Fast-Charge Port(s) |
No |
Industry Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab IEEE 802.3az Energy-Efficient Ethernet, IEEE 802.3x Flow Control, 802.1q VLAN Tagging, 802.1p Layer 2 Priority Encoding |
Interface |
USB 3.1 – Backward compatible with USB 3.0, 2.0 and 1.1 USB 3.1 RJ45 (Gigabit Ethernet) |
Ports |
3 |
USB-C Device Port(s) |
No |
USB-C Host Connection |
Yes |
PERFORMANCE |
|
Auto MDIX |
Yes |
Auto-Negotiation |
Yes |
Compatible Networks |
10/100/1000 Mbps |
Flow Control |
Full duplex flow control |
Full Duplex Support |
Yes |
Jumbo Frame Support |
4K max. |
Maximum Data Transfer Rate |
10 Gbps (USB 3.1) 2 Gbps (Ethernet; Full-Duplex) |
Type and Rate |
USB 3.1 – 10Gbps |
CONNECTOR(S) |
|
Connector Type(s) |
3 – USB Type-A (9 pin) USB 3.1 Female 1 – RJ-45 Female 1 – USB Type-C (24 pin) USB 3.1 (Gen 2) Male |
SOFTWARE |
|
OS Compatibility |
Windows® XP, Vista, 7, 8, 8.1, 10, 11 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016 Mac OS® 10.6 to 12.1 Chrome OS™ Linux 2.6.x to 4.4.x LTS versions only |
SPECIAL NOTES / REQUIREMENTS |
|
Note |
The hub does not support DisplayPort Alt Mode, or USB Power Delivery |
System and Cable Requirements |
Available USB Type-C port – USB 3.0 (5Gbps) |
INDICATORS |
|
LED Indicators |
1 – Power |
ENVIRONMENTAL |
|
Humidity |
0%~85% RH (Non-condensing) |
Operating Temperature |
0°C to 50°C (32°F to 122°F) |
Storage Temperature |
-10°C to 70°C (14°F to 158°F) |
PHYSICAL CHARACTERISTICS |
|
Colour |
Black |
Enclosure Type |
Aluminium |
Size & Weight |
7.5x3x1.7cm / 40g |
WHAT’S IN THE BOX |
|
Included in Package |
1 – VL-HJ45-C2 1 – driver cd 1- user manual |
