Description
SPECIFICATIONS:
Bus Type |
PCI-E 5.0 |
Primary Clock Speeds |
Base Clock Up To: 1900 MHz Game Clock Up To: 2780 MHz Boost Clock Up to: 3320 MHz |
Stream Processors |
2048 |
Compute Units |
32 |
Memory Bus |
128bit |
Memory Clock |
20 Gbps |
Memory Size |
16 GB |
Memory Bandwidth |
Up to 340 GB/s |
Memory Type |
GDDR6 |
Card Profile |
Dual Slot |
Thermal Solution |
3 Fan |
Outputs |
DisplayPort 2.1: 2x HDMI™ 2.1: 1x |
Requirements |
External Power: 1x PCI-E 8 pin connections Minimum Power Supply Requirement: 450 watt |
Certifications |
RoHS |
Estimated Dimensions |
Card Dimension (cm) 29 x 12.4 x 4.9 Card Dimension (inch) 11.42 x 4.88 x 1.93 |
Technologies |
32 AMD RDNA™ 4 Compute Units(with RT+AI Accelerators) AMD Infinity Cache™ technology DisplayPort™ 2.1 AMD Radiance Display™ Engine AMD Radeon™ Boost technology* AMD Radeon™ Anti-Lag* technology* 16GB GDDR6 on 128-Bit Memory Bus PCI® Express 5.0 ready AMD FidelityFX™ technologies* AMD FidelityFX™ Super Resolution technology* Microsoft® DirectX® 12 Ultimate Microsoft® DirectStorage Vulkan® Optimized AMD smart technologies* AMD Software: Adrenalin Edition™ application AMD Noise Suppression* AMD Privacy View* AMD Radeon™ Super Resolution technology* AMD Link* AMD Freesync™ technology* |
Key Features |
HDMI™ 4K Support 4K H264 Decode 4K H264 Encode H265/HEVC Decode H265/HEVC Encode AV1 Decode AV1 Encode |
