Description


SPECIFICATIONS:
Bus Type |
PCI-E 5.0 |
Primary Clock Speeds |
Base Clock Up To: 1660 MHz Game Clock Up To: 2400 MHz Boost Clock Up to: 2970 MHz |
Stream Processors |
4096 |
Compute Units |
64 |
Memory Bus |
256bit |
Memory Clock |
20 Gbps |
Memory Size |
16 GB |
Memory Bandwidth |
Up to 640 GB/s |
Memory Type |
GDDR6 |
Card Profile |
3.5 slot |
Thermal Solution |
3 Fan |
Outputs |
DisplayPort 2.1: 3x HDMI™ 2.1: 1x |
Requirements |
External Power: 2x PCI-E 8 pin connections Minimum Power Supply Requirement: 800 watt |
Certifications |
RoHS |
Package Contents |
Quick Installation Guide: 1 |
Estimated Dimensions |
Card Dimension (cm) 32.5 x 15 x 6.5 Card Dimension (inch) 12.8 x 5.91 x 2.56 |
Technologies |
64 AMD RDNA™ 4 Compute Units(with RT+AI Accelerators) AMD Infinity Cache™ technology DisplayPort™ 2.1 AMD Radiance Display™ Engine AMD Radeon™ Boost technology* AMD Radeon™ Anti-Lag* technology* 16GB GDDR6 on 256-Bit Memory Bus PCI® Express 5.0 ready AMD FidelityFX™ technologies* AMD FidelityFX™ Super Resolution technology* Microsoft® DirectX® 12 Ultimate Microsoft® DirectStorage Vulkan® Optimized AMD smart technologies* AMD Software: Adrenalin Edition™ application AMD Noise Suppression* AMD Privacy View* AMD Radeon™ Super Resolution technology* AMD Link* AMD Freesync™ technology* |
Key Features |
HDMI™ 4K Support 4K H264 Decode 4K H264 Encode H265/HEVC Decode H265/HEVC Encode AV1 Decode AV1 Encode |
